BOU-75S Series

BOU-75S Series

BOU-75S Series


  • Product No.: BOU-75S
  • Dimension: 127*76.2*30.5mm(3*5

Details

 Feature

Universal AC  Input85~265VAC/100~370VDC

Small Size,compact construction

Very wide working temperature (-25℃~70)

● Protection:Overload/Short/Over voltage

LED indicator,output voltage adjusted

All capacitor used high working temperature 105 & long life time type

2 year warranty

SPEC

Model  1

BOU-75S5

BOU-75S 12

BOU-75S15

BOU-75S 18

BOU-75S 24

BOU-75S 27

BOU-75S 48

Output

Output Voltage

5V

12V

15V

18V

24V

27V

48V

Setting Voltage(10%load)

5.00~5.05V

12.00~12.05V

15.00~15.05V

18.00~18.05V

24.00~24.10V

27.00~27.10V

48.00~48.10V

Rated Current(convention)

0~12.0A

0~6.25A

0~5.0A

0~4.17A

0~3.2A

0~2.78A

0~1.6A

Rated Output Power

60W

75W

75W

75.06W

76.8W

15.06W

76.8W

Ripple & Noise 0~70(2)

50mV

120mV

150mV

180mV

240mV

270mV

240mV

Ripple & Noise -25

120mV

360mV

360mV

360mV

360mV

360mV

480mV

DC adjustment range

-5% ~ +10% of rated output voltage

Output Voltage Tolerence

±2.0%

±2.0%

±1.0%

±1.0%

±1.0%

±1.0%

±1.0%

Setup time

≤1S (230Vac input, Full load)

Hold up time

≥25mS(230Vac input, Full load)

Output Inrush

<5.0%

Dynamic

10%-100%Load:10%Vp-p     10%-50%Load: 5%Vp-p   50%-100%Load: 5%Vp-p

Input

Input Voltage range

90Vac~264Vac

Rated Input Voltage

100Vac~240Vac

Start-up Voltage

85Vac

No load consumption

<0.5W

<0.8W

Efficient (Type)

81%

84%

85%

85%

86%

86%

88%

Input Current(Max)

<2.0A

Start-up Inrush Current

<20A@115Vac  <40A@230Vac Cold start
